Ergotron LX HD - Stud Mounting Installation Details; Drilling for Stud Mounting; Concrete Mounting Requirements

888-45-198-W-01 rev.B • 02/14
5 of 12
a
b
c
Ø 3/8"
(10 mm)
3-1/8"
(80 mm)
SVENSKA
WARNING:
Mounting holes must be at least 3-1/8” (80mm) deep and must be located within
solid concrete, not mortar or covering material. If you drill into an area of concrete
that is not solid, reposition mounting holes until both anchors can be fully inserted
into solid concrete!
Träregelsmontering
