Ergotron NeoFlex - Page 11

888-24-075-W-01 rev. J • 02/14
11/19
a
b
WARNING
DO NOT load Cart below minimum or above
maximum weight capacities. DO NOT mount a
display larger than the recommended size.
Failure to comply with warning may result in
Cart instability leading to equipment damage or
personal injury.
Min. 11 lbs (5 kg)
Max. 46 lbs (20.9 kg)
Min. 14 lbs (6.35 kg)
Max. 49 lbs (22.2 kg)
8”
(203mm)
a
b
*
Shelf Clearance
9”
(229mm)
11”
(280mm)
13”
(330mm)
4x
M6 x 14mm
8x
M6 x 14mm
7
8”
(203mm)
8
M5 x 8mm
1x
16 - 30 lbs
(7.3 - 13.6 kg)
< 2 lbs (0.9 kg)
< 3 lbs (1.4 kg)
A
B
C
A
+B+C= 14 - 53 lbs (6.35 - 24 kg)
ENGLISH
Optional Camera Shelf (ordered separately)No Camera Shelf
