888-24-075-W-01 rev. J • 02/14
12/19
9
A
B
C
D
75x75mm
100x100mm
100x200mm
200x200mm
200x100mm
100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
200mm (7-7/8”)
200mm (7-7/8”)
200mm (7-7/8”)
100mm (3-15/16”)
200mm (7-7/8”)
13
14
14
14
ENGLISH
VESA Adapter
Con gurations
TV/Monitor Hole
Pattern Sizes
Check size of
TV/Monitor hole
pattern
