Erickson 07706 - Page 2

Item no: 07706
1. Slide 2 mounting sleeves (14) onto one of the cross bars (4). Insert the triangular stops(13) into the
mounting sleeve(14), secure with M8*25 Bolts(15) and 8 washers(16),8 spring washers(17),M8
nuts(18). Repeat for 4 triangular stops.
2. Take the bottom of the post (3) and line up the holes on the post (3) with the holes for the
base(1&2), secure with M16*85 bolts (9), 16 washers (10), 16 spring washers (11) and M16 lock nut
(12). Repeat for 4 posts and bases.
3. Place the base that connecting with post(3) on the side rail of truck bed, secure with clamp(5), and
tighten with M12 nut(8), 12 washer(6), and 12 spring washer(7). Repeat for 4 bases.






M8 * Bolt 8x
Mounting sleeve 4x
8 Washers 8x
8 Spring Washers 8x
M8 Nut 8x
Cross Bar 2 x
Triangular stop 4x









M16* 85 Bolt 8x
16 SpringWasher 8 x
16 Washer 8 x
Post 4x
Base B 2 x
Base A 2 x
12 Washer 8x
M12 nut 8x
12 Spring Washer
Clamp 8 x
M16 Lock nut 8x




