Ge11799A
Unit of measurement: mm
200 200
200
Figure 14 Pole Installation, Dual Radio
3.2.4.1 Site Layout
To ensure adequate airflow between the units, allow a minimum of 50–200
mm free space, depending on band combination and Single Radio or Dual
Radio, above and below each radio. Refer to Pole Installation on page 17.
Radio Description
18
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08
