Valipass® form: Refer to the Valiquest® section for details.
Control panel
Sampling port for the manual filter saturation test or for an ambient air sensor when
the machine is equipped with the Molecode™ S option.
Yellow indicator light
Green indicator light
Red indicator light
Red indicator light
Digital display screen
Confirmation buttonNavigation button
Ventilation
switch
Internal light
switch
For information on the various scenarios related
to the triggering of the device’s indicator lights and
audible alerts, refer to the EVENT ALERTS section
of the FIRST START-UP chapter.
7
Fuse tag.
100-240
