Captair Smart
- European fan connection:
Reconnect the power supply to the fan hood
and the hose to the sampling port.
(If the device is tted with a type A or F Molecode)
When reassembling the ltration column, be
sure that the fan module is positioned correctly
to access your connection points.
Air Flow
- North American fan connection:
Reconnect the power supply to the fan hood
and the hose to the sampling port.
(If the device is tted with a type A or F Molecode)
Air Flow
When reassembling the ltration column, be
sure that the fan module is positioned correctly
to access your connection points.
