erlab Captair Smart 714 - Filter Column Configurations (392-714 Models)

33
User Manual
1C 2C
1P 2P
1P1C 1P2C
1C1P
2C1P
1P1C1P
Models Captair 392 - 483 - 633 - 714 Smart
1. Identify wich column conguration below applies to your hood. (See your Valipass label)
2. Unstack the ltration column(s) above the fume hood.
3. After carrefuly removing the lters from their packaging, assemble the column per the conguration below.
4. If your column conguration changed, Apply the correct fan setpoint for the ltration column conguration
(see fan setpoints)
