ero electronic PKP - LINKED PROGRAM MANAGEMENT; HOW TO CREATE A LINKED PROGRAM

A. 11
TABLE 2TABLE 2
TABLE 2TABLE 2
TABLE 2
Configuration group 1 [C.dxx]Configuration group 1 [C.dxx]
Configuration group 1 [C.dxx]Configuration group 1 [C.dxx]
Configuration group 1 [C.dxx]
PARAM. VALUE NOTES
Ln.Fr 60 Hz
ñ.In.t 18 (TC K with °F)
ñ.In.d ----. (No decimal figure)
ñ.In.S dIS Disabled
ñ.In.L -150 °F
ñ.In.H 2500 °F
OFSt 0 °F
dS.FL 0 (No filter)
A.In.F nonE
A.In.t 4-20 mA
A.In.L 32 °F
A.In.H 1832 °F
A.I.FL 0 (No filter)
Configuration group 2 [C.Exx]Configuration group 2 [C.Exx]
Configuration group 2 [C.Exx]Configuration group 2 [C.Exx]
Configuration group 2 [C.Exx]
PARAM. VALUE NOTES
O1.Fn ñAin If servo motor drive is not mounted
ALr.1 If servo motor drive or linear output
is mounted
O2.Fn ALr.2
O3.Fn nonE If option is not mounted
ñC.Sñ If servo control motor drive is
mounted
ALr.3 If option is mounted
O4.Fn nonE If option is not mounted
Alr.4 If option is mounted
Sñ.tP CLSd If feedback circuitry is mounted
OPEn If feedback circuitry is not mounted
FEEd no.Fb
O5.Fn nonE If option is not mounted
ñAin If option is mounted
O5.rn 4-20 4-20 mA
O5.Lr 32 °F
O5.Hr 1832 °F
O5.FL 0 No filter
O6.Fn nonE If option is not mounted
SP.rt If option is mounted
O6.rn 4-20 4-20 mA
O6.Lr 32 °F
O6.Hr 1832 °F
O6.FL 0 (No filter)
