ERS ECH Series - Page 72

Fig.8-9 ECH030N top view
Low pressure
switch
Solenoid valve
SV4
High pressure
sensor
Four-way valve
High pressure
switch
Electronic
expansion valve
Discharge
temperature
switch
High pressure
gauge point
Low pressure
gauge point
Accumulator
17
V.2
