⑧
⑨
⑥
①
12
④
③
⑤
⑦
②
11
10
Quick Assembly-Overview
① Base frame
② Printing surface
③ Extruder
④ Gantry frame
⑤ Ery Sensor
⑥ Extruder stepper motor
⑦ SD card slot
⑧ Power switch
⑨ Power cable port
⑩ LCD screen
⑪ USB cable port
⑫ Filament holder
1
