3 TECHNICAL DATA
LAF 1601 LAF 1601M
Mains connection 400/415/500 V, 3~ 50 Hz 230/400/415/500 V, 3~ 50 Hz
440/550 V, 3~ 60 Hz 230/440/550V, 3~ 60 Hz
Primary current I
max
136 A 230 A
Permissible load at:
100% duty cycle 1600 A / 44 V 1600 A / 44 V
Setting range 100–1600 A / 24–44 V 100–1600 A / 24–44V
No-load voltage 56 V 56 V
No-load power 230 W 230 W
Efficiency 88% 88%
Power factor at maximum
current 0.84 0.84
Apparent power I
2
at
maximum current 95.6kVA 87.5 kVA
Active power I
2
at
maximum current 80 kW 80 kW
Continual sound pressure
at no-load < 70 dB(A) < 70 dB(A)
Weight: 585 kg 585 kg
Dimensions L x W x H: 774 x 598 x 1430 mm 774 x 598 x 1430 mm
Insulation class
(transformer)
H H
Enclosure class IP 23 IP 23
Application class
