-- 1 0 6 --bc14s12a
c=component designation in the circuit diagram
Item 265 320 Ord.No. Denomination Remark c
301 1 1 455 816--001 Attachment
302 1 455 890--892 Wire feeder
302 1 455 890--893 Wire feeder
303 1 1 455 839--001 Air outlet grill
304 1 1 455 838--001 Fan
305 1 1 469 474--001 Brake hub
306 1 1 469 377--001 Connection block XT3
307 1 1 469 378--001 Insulation
305
303
304
302 301
307
306
