-- 1 0 7 --bc14s12a
c=component designation in the circuit diagram
Item 265 320 Ord.No. Denomination Remark c
-- 1 455 890--882 Feed unit Compl.
-- 1 455 890--883 Feed unit Compl.
400 1 367 529--001 Pressure arm
1 469 833--880 Pressure arm
401a 1 455 906--001 Spacer sleeve
401b 1 367 907--013 Geared adapter
402a 1 455 907--001 Pressure roller
402b 1 369 728--001 Pressure roller
466 262--001 Pressure roller Knurled
403 1 1 Locking washer SGA D8
404 1 1 Holder
405 1 1 Shaft
406 1 1 455 896--001 Spring
1 1
408 1 1 466 489--001 Drive unit M01
409 1 1 2157 01--007 Locking washer
410 1 1 191 496--114 Key
411 1 1 466 074--001 inlet nozzle
412 1 1 367 528--001 Pin bolt
413 1 1 368 749--880 Pressure transducer
414 1 1 368 750--001 Insulating sleeve
415a 1 1 455 894--001 Insert tube Plastic
415b 1 1 455 889--001 Insert tube Steel
416a 1 1 455 885--001 Outlet nozzle with item 415a
416b 1 1 455 886--001 Outlet nozzle with item 415b
417 1 1 455 882--001 Current sleeve
418 1 1 455 883--001 Spacer sleeve ø 16/8.2x0.9
419 1 1 Washer ø 16/8.4x1.5
420 1 1 Screw M8x20
421 1 1 455 881--001 Protection plate
422 1 1 2152 012--02 O--ring
423 1 1 455 898--001 Screw M5x12
424 1 1 Screw M4x12
