-- 1 0 4 --bc14s12a
c=component designation in the circuit diagram
Item 265 320 Ord.No. Denomination Remark c
201 1 1 191 870--616 Potentiometer 10 kW RP1
202 1 1 193 260--062 Connector 3--way XS4
203 1 1 366 295--002 Switch QF1
204 1 1 193 945--001 Switch 10 step SA2
205 1 1 369 733--005 Light--emitt. diode Yellow V7
206 1 1 369 733--007 Indicating lamp 42 VAC, white HL1
207 1 1 Knob Included in item 204
2 Knob Incl. in item 204,213
208 1 1 366 296--003 Knob
209 2 1 321 475--882 Knob
210 1 455 607--001 Panel with text
1 455 608--001 Panel with text
211 1 1 455 172--001 Protection glass
212 1 1 455 174--001 Seal
213 1 193 942--001 Switch 4step SA1
214 1 1 456 008--880 Digital instrument Option comp. P1
215 1 1 486 317--880 Circuit board Dig. instr.
216 2 2 455 226--010 Spacer
1 1 455 226--004 Spacer
217 1 193 951--001 Potentiometer 10kτ, with switch RP2
