17
SECTION 4 OPERATION
Weld Process
Switch
Current Set
Wire Feed
Speed Trim
IPM
Figure 8 - Control Panel
Positive Output
Connection
Negative Output
Connection
Temperature
Lamp
Voltage Set
Main
Power
Switch
Wire Feed Speed
Hot Start
Figure 9 - Front Panel
