Item No. Part No. Description Cct. Ref.
1 0558002626 Multimaster 160
2 0558002704 Lid with Handle/Strap (Not Shown)
3 0558002735 Knob Ø 25mm
4 0558002736 Knob Ø 22mm
5 0558002707 Connector Dinse 25 +, -
6 0558002708 Bottom Plate
7 0558002709 MIG EURO Connector
8 0558002710 Wire Feeder Assembly
Includes:
0558002795 Feed Motor
9 0558002711 Reel Hub
10 0558002738 Fan VR1 & 2
11 0558002739 Fan Grid
12 34574 Mains Power Cable w/Plug 10Ft.
13 0558002746 EMI Filter
14 0558002716 Inverter AC PCB
15 0558002717 Control PCB
16 0558002747 ON/OFF Switch S1
17 0558002719 Solenoid Valve Assembly
18 58V58 Bulkhead Adaptor for Gas Fittings
19 136Z08 Gas Inlet Nut
20 35N22 Gas Inlet Nipple
21 0558002711 Spacer for Reel Hub
22 21161 Serrated Feed Roll 0.9 - 1.0mm
23 21156 Solid Wire Feed Roll 1.0 - 1.2mm
Spare Parts List
MultiMaster 160
SECTION 6 REPLACEMENT PARTS
