19
Choiceof12’or15’Gun
Master 250 Mig Gun
HW-17 Tig Torch
(Optional)
Stick Electrode
Holder
(Optional)
15’WorkCable
and Clamp
Choice of Argon or CO
2
Regula-
tor/Flowmeter
Simple To Use Weld
Controls
Figure 1A - Components
Welding Gloves
(Optional)
Eyetech Auto-
matic Helmet
(Optional)
Factory Installed
Two Cylinder Easy
Load Running Gear
Large, Easy To Read
Digital Displays for Wire
Speed, Amps and Volts
6’GasHose
Simple and quick
polarity change-over
Cylinder Safety
Chain
SECTION 2 INTRODUCTION
