ESAB Multimaster-260 Installation And Operation

26
Digital Meters
Amps/Volts/WFS
Power “ON”
Lamp
Temperature
Lamp
Fault
Lamp
WFS - IPM
Lamp
Amps
Lamp
Preset
Button
Weld Process
Switch
Voltage Set - MIG
Current Set - STICK/TIG
Wire Feed
Speed Trim
IPM
Figure 12 - Control Panel
Main
Power
Switch
Spool Gun Control
Module
(Option)
Remote Control
Module
(Option)
Mig Gun
NAS
Connection
Positive Output Con-
nection
Negative Output
Connection
Polarity Switch-
ing Connector
Mig Gun
Trigger
Receptacle
Figure 13 - Front Panel
SECTION 4 OPERATION
