45
QTY. ITEM CIRCUIT
No. REQ. NO. DESCRIPTION SYMBOL
1 952895 1 SWITCH PB NORMALLY OPEN S2
2 672831 1 SWITCH TOGGLE SPDT S3
3 951474 1 SWITCH SEALL BLACK
4 0558001702Y 1 BRACKET RH HANDLE
5 13730632 2 POT LIN 10.0K 2.00W .88L R1,R2
6 0558001019 2 KNOB 1.57 DIA. 0
7 182W64 1 LOCK TWIST MIDGET
8 2602336 1 PLUG (NOT SHOWN)
9 0558001492 1 COMPACT/NAS TORCH ADAPTOR includes:
23610528 1 HOUSING
0558001493 1 BLOCK ASSY.
0558001495 1 SCREW ASSY.
23612350 1 POWER LUG
0558001494 1 CONN. TUBE ASSY.
10 0558001854 1 RECESSED HANDLE
11 0558001867 1 POLARITY CABLE ASSY.
12 0558001576 2 WHEEL SPOKE 10” x 2.252” POLY
13 0558001699G 1 AXLE REAR
14 13733935 2 PANEL RECEPT
15 950396 2 CASTER WHEEL
16 0558001688Y 1 COVER BOTTOM RIGHT
17 0558001687G 1 COVER BOTTOM FRONT
18 1 REMOTE CONTROL & SPOOL GUN (OPTIONS SHOWN)
19 0558001574 1 SWITCH POWER 40A 600V
20 0558001629 1 PANEL CONTROL KYDEX
21 950904 1 OVERLAY FRONT PANEL MM260
22 0558001011 1 PCB BOX
23 0558001703Y 1 BRACKET RH HANDLE
24 36356 1 HANDLE
25 0558001495 1 NAS TORCH SECURING SCREW ASSY.
26 0558001836 1 NUT, CONNECTION TUBE
27 0558001837 1 O-RING
Figure 24 - Right Side Front View (Con’t)
SECTION 6 REPLACEMENT PARTS
