ESAB Origo Mig C141 User Manual

- 7 -
ba47e
Mag C171Mig C151Mig C141
Operating temperature -10 ÷ +40
o
C -10 ÷ +40
o
C -10 ÷ +40
o
C
Enclosure class IP 23 IP 23 IP 23
Application classifica
tion
Mag C201 Mag C251
Voltage 220-230V, 1∼ 50/60Hz 220-230V, 1∼ 50/60Hz
Permissible load at
100% duty cycle 90A/18.5V 110A/19.5V
60 % duty cycle 115A19.7V 140A/21.0V
30 % duty cycle - 200A/24.0V
23 % duty cycle 185A/23.3V -
20 % duty cycle 200A/23.0V 250A/21.0V
Setting range (DC) 30A/15.5V-185A/23.3V
(200A/23.0V)
40A/16.0V-200A/24.0V
(250A/21.0V)
Open circuit voltage 19.6-44.9V 19.0-41.5V
Open circuit power 120W 200W
Power factor at max load 0.89 0.92
Control voltage 42V, 50/60Hz 42V, 50/60Hz
Wire feed speed 1.0-17m/min 1.9-19m/min
Burnback time 0.02-0.25s 0-0.25s
Spot welding 0.2-2.5s 0.2-2.5s
Welding gun connection EURO EURO
Wire dimension range 0.6-1.0(Fe)
1.0(Al)
0.8-1.0(cored)
0.8-1.0(CuSi)
0.6-1.2(Fe)
1.0-1.2(Al)
0.8-1.2(cored)
0.8-1.0(CuSi)
Max diameter/weight
of wire bobbin
300mm/15kg 300mm/15kg
Dimensions lxwxh 860x420x730 860x420x730
Weight 68kg 94kg
Operating temperature -10 ÷ +40
o
C -10 ÷ +40
o
C
Enclosure class IP 23 IP 23
Application classifica
tion
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or cut at
a certain load without overloading. The duty cycle is valid for 40° C.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
GB

ESAB Origo Mig C141 Specifications

General

Output Current Range	30 - 140 A
Fuse (slow)	16 A
Enclosure Class	IP 23
Rated Input Current	16 A
Wire Diameter	0.6 - 1.0 mm
Protection Class	IP 23
Power Supply	1 Phase
Wire Feed Speed Range	2 - 12 m/min
