Control Panel
THE CONTROL PANEL
Figure 3- Control panel
1. On/O button: switches the dishwasher On and O.
2. Half-load Function button: this activates the Half-load function. Use this when you have less than 7 place settings
of dishes, saving both energy and water consumption. This can only be used with the Intensive, ECO and 90 Min
wash programs.
3. Delay button: Press the button to set a delayed start time.
4. Child lock function: Simultaneously press the Delay and Half-load buttons to activate child lock.
5. Rinse Aid indicator: Indicates when the rinse aid is low and that the dispenser needs to be relled.
6. Program Ended indicator: Indicates when the dishwasher program has been completed.
7. Half-load function indicator: LED indicates whether the ½ load function is activated or not.
8. Child lock indicator: LED indicates whether the child lock function is activated or not.
9. Intensive Program indicator: LED indicates whether this program is selected or not.
10. ECO Program indicator: LED indicates whether this program is selected or not.
11. 3h/6h/9h Delay Start indicators
12. Extra Drying indicator: LED indicates whether the Extra Drying function is activated or not.
13. 90min Program indicator: LED indicates whether this program is selected or not.
14. Rapid Program indicator: LED indicates whether this program is selected or not.
15. Program button: Press this button to cycle through the program options (i.e. Intensive, Glass, Eco, etc)
16. Extra Drying button: Press this button to activate the Extra Drying function. This function will heat the water to a
hotter temperature during its nal rinse cycle, creating extra heat. It can only be used with the Intensive, ECO and
90min programs.
17. Start/Pause button: Press this button to start the selected washing program or pause the washing program when
running.
1 2 3
4
5
171615
6 7 8 9 10
11 12 13 14
