This document is a user manual for the Esatto EO605MS 60cm 5 Function Built-in Oven.

Function Description

The Esatto EO605MS is a built-in oven designed for domestic use. It offers five cooking functions:

Grill: This function uses the inner grill element for everyday grilling, directing heat downwards onto the food.
Grill & Fan: This function combines the inner grill element with the fan, making it suitable for grilling a large amount of food.
Convection: This function circulates heat from the rear heating element throughout the cavity by the fan. It is an economical and conventional cooking method that also helps food cook faster whilst reducing hot and cool spots and helping dishes on every shelf cook more evenly.
Defrost: This function circulates room temperature air without any heating elements. It gently and quickly speeds up the defrosting time and thawing of ready-made dishes, cream-filled produce, etc.
Oven Light: This function allows the user to observe the progress of cooking without opening the door. The oven lamp will light for all cooking functions.

The oven features a control panel with a Function Knob, Timer Knob, Temperature Knob, and a Preheat Indicator. It also includes a manual cooking mode where the cooking duration is controlled by the user without a timer. The timer knob can be set to engage manual cooking mode or to turn off the oven after a set number of minutes. The temperature knob and function knob are used to set the desired cooking settings.

Important Technical Specifications

Model: EO605MS
Gross Volume: 80L
Product Dimensions (W × D × H): 595 × 575 × 595mm
Weight (Net/Gross): 32kg / 36kg
Rated Voltage: 220-240V~
Rated Frequency: 50Hz-60Hz
Rated Power: 2.1kW
No. of Functions: 5

Usage Features

The oven is supplied with accessories including:

2 x Wire Shelves: For grilling, dishes, cake pan with items for roasting and grilling.
2 x Slide Brackets: These shelf support rails on the right and left sides of the oven can be removed.
1 x Baking Tray: This tray can be placed on the oven base, using the Grill and Grill & Fan functions, for cooking large quantities of food such as cakes, pastries, frozen food, etc., or for collecting fat/spillage and meat juices.

Shelf Placement: To ensure safe operation, correct placement of the shelves between the side rail is imperative. Shelves and the pan can only be used between the first and fifth layers. The shelves should be used with the right direction, ensuring that during careful removal of the shelf or tray, hot food items do not slide out.

Before First Use:

Before using the oven for the first time, users should read the manual thoroughly to familiarize themselves with the installation and operation instructions.
After the appliance has been properly installed and before first use, it is recommended to burn off any dust, oil or other contaminants that may have been left inside the cavity from the manufacturing process or transportation. This can be done by running the empty oven with the conventional cooking function at 250°C for at least 90 minutes.

Ventilation: When cooking is finished, or in a paused or standby state, and if the oven cavity temperature is over 75 degrees, the cooling fan will operate for 15 minutes or until the oven cavity temperature becomes lower than 75 degrees. Ventilation openings are present to facilitate this cooling process.

Installation Instructions: The oven must be fitted into the space provided in the kitchen unit, ensuring it is mounted underneath a worktop or into an upright cupboard. The oven is fixed in position by screwing into place, using the two fixing holes in the frame. To locate the fixing holes, open the oven door and look inside. Adequate ventilation, measurements and distances adhered to when fixing the oven are crucial. The kitchen unit material must be heat resistant, capable of withstanding temperatures of at least 120°C. Plastic or glued parts that cannot withstand high temperatures will melt and deform the unit. All parts must be completely insulated. The electrical parts must be firmly fixed into place so that it is impossible to remove them without using special tools. The rear of the kitchen unit must ensure an adequate current of air circulates around the oven. The hob must have a rear gap of at least 45mm. The cavity is not to include the power switch or socket. The oven and cabinet dimensions are in millimetres.

Safety Instructions:

Always follow basic safety precautions and accident prevention measures when using an electrical appliance.
The appliance is for domestic household use only and is not intended for commercial, industrial or outdoor use.
Do not use this appliance for anything other than its intended purpose.
Attachments not recommended by the appliance manufacturer or distributor may be hazardous.
Damage due to improper use or repairs made by unqualified personnel will void the warranty.
Keep the manual in a safe place for future reference, along with the completed warranty card and purchase receipt.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction for safe operation.
Children should be supervised to ensure they do not play with the appliance.
Keep all packaging away from children.
Keep children and pets away from the appliance door when it is open.
Do not allow children to go near the oven when it is operating, especially when the grill is on.
Cleaning and user maintenance should not be made by children without supervision.
The appliance must be earthed.
Ensure the electrical information on the rating plate agrees with the power supply.
Always use a correctly installed shockproof socket.
Do not use any multi-plug adapters or extension cables.
Connect the mains plug to the mains socket only at the end of the installation.
Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
Do not touch the mains cable or the mains plug with wet hands.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or similarly qualified person.
All electrical work must be done in accordance with local and national electrical codes.
Do not use this appliance in a household only.
Do not change the specification of this oven.
Do not sit or stand on the open door.
Please do not close the machine door with excessive force.
When the door or drawer of oven is open do not lean anything on it.
The appliances are not intended to be operated by means of an external timer or separate remote-control system.
The instructions for ovens that have shelves shall include details indicating the correct installations of the shelves.

Maintenance Features

Prior to Cleaning Your Oven:

Before any maintenance and cleaning, turn off the appliance and disconnect the power.
Set all controls in the OFF position.
Wait until the inside of the unit is not hot but only slightly warm—cleaning is easier than when warm.
Clean the surface of the unit with a damp cloth, soft brush or fine sponge and then wipe dry.
In case of heavy soiling, use hot water with non-abrasive cleaning product.
For cleaning the oven door glass, do not use abrasive cleaners or sharp metal scrapers, as these can scratch the surface or lead to the glass being damaged.
Never leave acidic substances (lemon juice, vinegar) on stainless steel parts.
Do not use a high pressure cleaner for cleaning the unit.
The baking tray and wire shelving may be washed in mild detergent.

Bulb Replacement:

Disconnect power from the mains outlet or switch off the circuit breaker of the unit's mains outlet.
Unscrew the glass lamp cover by turning it counter-clockwise (note, it may be stiff) and replace the bulb with a new one of the same type.
Screw the glass lamp cover back in place.

Only use 25W/230V, T300°C halogen lamps.

Removing the Oven Door & Inner Glass: The removable door allows for full access to the entire interior of the oven for easier and quicker maintenance.

To remove the door, open the door to the maximum angle. Then pull the buckle at the door hinges backward.
Close the door to an angle approximately 30°. Hold the door with one hand on each side. Lift up and slowly pull the door out from the oven.
Open the door rotation bracket assembly, refer to image on the right.
Lift up the door outer glass and pull it out.
Then take the door middle glass out using the same method as step 4.
When cleaning is completed, reverse the above procedures to return the door to its original position.

Do not forcefully pull out the door or glass to prevent breaking the glass during dismantling.
The hinge springs could become loose and cause personal injury.
Do not lift or carry the oven door by the door handle.

Care & Cleaning:

Before maintenance, deactivate the appliance and disconnect the mains plug.
Do not use a steam cleaner on the appliance.
Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.
Do not use harsh abrasive cleaners, sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.

Unpacking:

During transportation, protective packaging was used to protect the appliance against any damage.
After unpacking, please dispose of all elements of packaging in a way that will not cause damage to the environment.
All materials used for packaging the appliance are environmentally friendly; they are 100% recyclable and are marked with the appropriate symbol.
During unpacking, the packaging materials (polythene bags, polystyrene pieces, etc.) should be kept out of reach of children.

Disposal of the Appliance:

Disconnect the appliance from the mains supply.
Cut off the mains cable and discard it.
Remove the door catch to prevent children and pets getting closed in the appliance.
Old appliances should not simply be disposed of with normal household waste and should be delivered to a collection and recycling centre for electric and electronic equipment.
Materials used inside the appliance are recyclable and are labelled with information concerning this.
By recycling materials or other parts from used devices you are making a significant contribution to the protection of our environment.
Information on appropriate disposal centres for used devices can be provided by your local authority.

Declaration of Compliance:

When you have unpacked the oven, make sure that it has not been damaged in any way. If you have any doubts at all, do not use it. Contact a professionally qualified person.
Keep packaging materials such as plastic bags, polystyrene, or nails out of the reach of children because these are dangerous to children.
