PRIOR TO CLEANING YOUR OVEN
WARNING:
• Before ny mintennce nd clening, turn o
the pplince nd disconnect the power.
• Set ll controls in the OFF position.
• Wit until the inside of the unit is not hot but only
slightly wrm—clening is esier thn
when wrm.
• Clen the surfce of the unit with  dmp cloth,
soft brush or ne sponge nd then
wipe dry.
• In cse of hevy soiling, use hot wter with non-
brsive clening product.
• For clening the oven door glss, do not use
brsive cleners or shrp metl scrpers,
s these cn scrtch the surfce or led to the
glss being dmged.
• Never leve cidic substnces (lemon juice,
vinegr) on stinless steel prts.
• Do not use  high pressure clener for clening
the unit.
• The bking try nd wire shelving my be
wshed in mild detergent.
BULB REPLACEMENT
For replcement, follow the below process:
1. Disconnect power from the mins outlet or
switch o the circuit breker of the unit’s mins
outlet.
2. Unscrew the glss lmp cover by turning
it counter-clockwise (note, it my be sti)
nd replce the bulb with  new one of the
sme type.
3. Screw the glss lmp cover bck in plce.
NOTE:
Only use 25W/230V , T300°C hlogen lmps.
REMOVING THE OVEN DOOR  INNER GLASS
The removble door llows for full ccess to the
entire interior of the oven for esier nd quicker
mintennce. Follow these instructions crefully
if you wish to remove the over door.
1. To remove the door, open the door to the
mximum ngle. Then pull the buckle t
the door hinges bckwrd.
2. Close the door to n ngle pproximtely 30°.
Hold the door with one hnd on ech side. Lift up
nd slowly pull the door out from the oven.
3. Open the door rottion brcket ssembly,
refer to imge on the right.
4. Lift up the door outer glss nd pull it out.
5. Then tke the door middle glss out using the
sme method s step 4.
6. When clening is completed, reverse the
bove procedures to return the door to its
originl position.
WARNING:
• Do not forcefully pull out the door or glss to
prevent breking the glss during dismntling.
• The hinge springs could become loose
nd cuse personl injury.
• Do not lift or crry the oven door
by the door hndle.
Mintennce  Clening
BULB REPLACEMENT
For replacement, process as follows:
1> Disconnect power from the mains outlet or switch off the circuit breaker of the unit's mains outlet.
2> Unscrew the glass lamp cover by turning it counter-clockwise (note, it may be stiff) and replace
the bulb with a new one of the same type.
3> Screw the glass lamp cover back in place.
NOTE: Only use 25-40W/220V-240V, T300°C halogen lamps.
