ESCALADE Goliath Prodigy B2255EF - Page 26

26
HARDWARE NEEDED (ACTUAL SIZE)
3/8-16 X 6.25" HHCS, GRADE 5
1B-7188-00
QTY. 1
23
9/16”
TOOLS NEEDED
9/16”
Before proceeding to the next step have the hardware and tools ready along at least 3 other
capable people, read the next page completely and understand it before beginning the next step.
ASSEMBLY TIP
3/8" WASHER
701-50
QTY. 2
36
NYLON WASHER,
0.38 ID X 1.25 OD
3M-6883-00
QTY. 2
34
3/8-16 LOCKNUT
901-28
QTY. 1
42
