Switch.
Trim and cut.
145mm.
MOUNTING THE ENGINE
2) Use a pin drill and 2mm drill bit to drill a
small indentation in the mount for the engine
mounting screw.
3) Use a drill to drill the four holes in the engine
mount rails.
4) On the fire wall has the location for the
throttle pusshrod tube (pre-drill).
1) Position the engine with the drive washer
(145mm) forward of the firewall as shown.
4.5mm.
Pushrod tube hole.
4mm.
4.2mm.
