EScale Seafire - Kit Contents

3Seare Instruction Manual

Thank you for choosing the EScale Seare ARTF. The EScale Seare was designed with the intermediate/advanced
sport yer in mind. It is a semi scale airplane which is easy to y and quick to assemble. The airframe is conventionally
built using balsa plywood to make it stronger than the average ARTF, yet the design allows the aeroplane to be kept
light. You will nd that most of the work has been done for you already. The motor mount has been tted and the
hinges are pre-installed. Flying the EScale Seare is simply a joy.
This instruction manual is designed to help you build a great ying aeroplane. Please read this manual thoroughly
before starting assembly of your EScale Seare . Use the parts listing below to identify all parts.

1
2 3
4
4
5
6
7 8
9
99
9 9
1 Fuselage with canopy
2 Left wing panel
3 Right wing panel
4 Tail set
5 Aluminium wing tube
6 Fiberglass cowl
7 Retracts landing gear
8 EP conversion pack
9 Hardware bag included
aDDitionaL iteMS reQuireD
■ 0.75-0.91 2-stroke. or 0.91-1.00 4-stroke
■ Computer radio with 8 servos
■ Glow plug to suit engine
■ Propeller to suit engine
■ Protective foam rubber for radio system
■ Silicone fuel line
tooLS & SuppLieS neeDeD
■ Thick cyanoacrylate glue
■ 30 minute epoxy
■ 5 minute epoxy
■ Hand or electric drill
■ Assorted drill bits
■ Modelling knife
■ Straight edge ruler
■ 2mm ball driver
■ Phillips head screwdriver
■ 220 grit sandpaper
■ 90° square or builder’s triangle
■ Wire cutters
■ Masking tape & T-pins
■ Thread-lock
■ Paper towels
