B
11
Compulsory False Cavity Requirements
Ensure the replace is inserted rst before the wall lining is built.
For oor-mounted installaons, allow for fascia clearance, see B11 on page 15.
NOTE: Wall lining should hang below the lintel to meet the appliance edge.
NOTE: If your installaon requirements do not align with the diagram above, please contact our architectural
advisory team: aa@escea.com
B3 Floor Clearances
If the appliance is mounted above a “heat resistant oor” (including but not necessarily limited to: ceramic
les, concrete, and stone) then it may be posioned with the boom of the fascia level with the nished oor if
desired (30mm or 55mm spacer required under the re in this case depending on the fascia type).
If the appliance is mounted above a “heat sensive oor” (including but not necessarily limited to: carpets,
vinyl, carpet les, rugs and mats, mber, joinery, wooden ooring - see materials guide) then we recommend a
distance of 100mm from the boom of the fascia to the nished oor or hearth.
NOTE: Excerpt from AS/NZS 5601.1 Sec. 6.2.5. “A gas appliance shall be installed such that the surface
temperature of any nearby combusble surface will not exceed 65°C above ambient.”
Refer to secon B5 on page 12 for hearths.
B4
If a cavity is to be created in a corner, the following drawing gives the minimum
sized interior wall dimensions.
A B C
DF700 685mm 695mm 420mm
DF960 815mm 945mm 435mm
DF 20mm stando to
wall linings
Timber Stando to Lintel. Fold
Up to ensure clearance
requirements have been met.
Lintel clearances; must cover
the full width of the appliance
=
598mm
From Base of Unit
45º
C
B
A
To Next Page
