Escort EGC-3236A - Safety; Specification; General Specifications

5
General Specications
Display Mode 6 Digits of Seven Segment LED
Output Sine, Triangle, Square, Ramp, Pulse, TTL
Input Sweep, External counter and Modulation
Warm-up Time At least two hours
Operating Temperature 0°C~40°C (32°F to 104°F)
Storage Temperature -10°C to 60°C
Altitude Up to 2000 M
Relative Humidity
Up to 80% for 0°C to 28°C
Up to 70% for 28°C to 40°C
Dimensions 261 x 71 x 211mm
Weight 1.8kg
Line Voltage
AC 100V/120V (±10%) 50/60Hz, FUSE:0.4A/250V
AC 220V/240 (±10%) 50/60Hz, FUSE: 0.2A/250V
Power Consumption 40VA maximum
Ventilation
Always keep the back of instrument far away the wall for
better ventilation, and nothing at among.
Standard Accessories User Manual in CD-ROM/ Power cord
Safety
Designed in compliance with EN61010-1 (IEC1010-1)
Installation Category II, Pollution Degree 2 Environment
EMC Designed in compliance with EN61326
Specication
