Electrical Specications
The accuracy is given as ± (% of span + No. of least signicant counts) at 23°C ± 5°C with relative humidity
less than 80% R.H.
Main Output
Range (Sine/Triangle/Square Waves)
Output Range
Display Resolution Accuracy
Minimum Maximum
10mHz 1Hz 1mHz Not Specied
100mHz 10Hz 10mHz
±(3%+2)
1Hz 100Hz 100mHz
10Hz 1kHz 1Hz ±(0.3%+1)
100Hz 10kHz 1Hz or 0.001kHz
±(0.03%+1)
1kHz 100kHz 0.001kHz or 0.01kHz
10kHz 1MHz 0.01kHz or 0.1kHz
100kHz 10MHz 0.1kHz or 0.001MHz
Notes:
1. The specication is specied within 10% to 100% of maximum output range, and the waveform characteristics are limited to the
specied range also.
2. The display resolution and accuracy is relative to the span of internal counter.
3. Symmetry is specied within 2% at 1Hz~100kHz.
Waveform Characteristics
Triangle Wave Linearity
Frequency Linearity
1Hz ~100KHz > 98%
>100 KHz Not Specied
Sine Wave Distoration
Distortion Harmonic Ratio
10Hz ~ 100kHz 100kHz ~1MHz 1MHz ~10MHz
<2% <-30dB <-20dB
Notes:
1. The distortion isn’t specied for less than 10 Hz.
Square Wave
Transition time Aberration
< 30ns < 5% of P-P amplitude +/- 50 mV
