13
Kongsberg X-series
Parameter Description
Tool Height The tool tip should touch the material surface.
Lag Setting The knife lag depends upon the actual knife blade adapter and knife blade.
Tool Rotation Adjust tool angle tangential to moving direction.
Center Offset Adjust tool sideways until centered.
Tool Offset Adjust offset relative to Laser Pointer.
For more information about how to run the adjustment wizards, see Tool Configuration.
13.11. KissCut
KissCut is a special knife tool for vinyl
cutting.
The cutting depth is controlled by the
downward knife pressure.
For applications where a more accurate
depth control is required, a simple foot
solution is available.
The tool is prepared for a wide range of
Knife Blades.
Lag is nominal 0 mm.
Description
A complete KissCut tool consist of:
A - The tool body with knife adapter
B - Pressure unit no x (two models
available)
C - Locking knob
D - Knife Blade
E - Knife foot
F - Spanner
145
