Operation
Assuming the storage tanks and filters are filled and heated, the units can be placed
through its initial run. With the MAIN ON and PROGRAM 1 selected, pressing
the START CYCLE button will run a program cycle as shown in the following
table: (Use this grid to record time settings)
R3 Fill from Clean Tank
R4 Ultrasonic cleaning
R6 Drain to Clean Tank
R8 Fill from Rinse Storage Tank
R9 Ultrasonic rinse cascade to Rinse Storage Tank
R10 Ultrasonics rinse
R12 Drain to Rinse Storage Tank
R14 Fill from HST 3 (or 4) Acid Storage Tank
R15 Ultrasonic passivation
R16 Passivation - NO ultrasonics
R17 Drain to HST 3 (or 4) Acid Storage
R21 Fill from Rinse Storage Tank
R22 Ultrasonic rinse
R24 Ultrasonic rinse cascade to Rinse Storage Tank
R25 Drain to Rinse Storage Tank
R26 Fill from source
R27 Ultrasonic rinse overflow to Drain
R28 Ultrasonics rinse
R30 Drain to Drain
R31 Dry
R32 Dry with drain pump (20-30 seconds only)
R33 Dry
R34 Cool Down
R35 Alarm
Prog2 Prog3
Program Times (seconds)
Prog1
