Top Left – HST 4 (FUTURE Acid Tank)
Top Right – HST 1 (Clean Storage Tank)
Bottom Right – HST 2 (Rinse Storage Tank)
Bottom Left – HST 3 (Acid Storage Tank)
IMPORTANT TO MATCH THE PLUGS AND
RECEPLACLES OF THE TANKS.
Plumbing Hook-Up
When the system was wrapped up for shipping the hoses which were used in
testing were included and marked. In the event that the tanks are to be located in a
different orientation than was configured in the plant, additional hose will need to
be procured. If the system is set up with HST-1 thru 3 on the right of the washer
the process should be straight-forward (as illustrated, use markings on the included
hoses for connections), setup should be as illustrated below.
(HST1) (HST2) (HST3)
To Next Page
