Additional Settings (1)
Additional settings are available.
o See “Available setup items and settings” from the next page for
each setting.
Changing settings
1
Press and hold the SETUP button for more than
2 seconds.
Hold down
more than 2 sec.
“Disp>” appears on the display and the unit enters the setup
mode.
2
Press the SETUP button repeatedly to select the menu
item to be set.
Each time the SETUP button is pressed, the item changes as
follows:
Disp>
VolTable>
PreOut>
POutLv
RCA2>
RCA3>
MM/MC>
XLR1 =
XLR2 =
RCA1 =
RCA2 =
RCA3 =
FLaOFF>
Setup>
Return to the previous display
(Exit setup mode)
Volume display
Volume curve
Pre out
Pre out output level
RCA2 throughout
RCA3 PHONO input
PHONO Cartridge
Assigning input terminal names/
Setting input terminal to be skipped
Auto display darkening
Returning to factory settings
o The item names will change according to the current input
terminal or settings you have made.
o If no button is pressed for more than 10 seconds or the CLEAR
button is pressed, the setup mode will be canceled and return
to the previous display.
3
Press the INPUT buttons (</>) to change the setting.
See “Available setup items and settings” from the next page for
each setting.
Repeat steps
2
and
3
as required.
4
Press the SETUP button repeatedly to exit the setup
mode.
o You can also press the CLEAR button or wait for more than
10 seconds to exit the setup mode.
o Memorized settings are stored even after the power cord has
been disconnected.
