Connections
After all other connections are complete, connect the power cord plug to the AC wall socket.
o Read the instructions of each component you intend to use with this unit.
o Be sure to connect each plug securely. To prevent hum and noise, do not bundle the connection cords.
A
A
B
C
D
XLR cable
RCA audio cable
RCA audio cable
Power cord
LRLR
LR
Turntable
Recorder etc.
Super Audio CD Player
etc.
Super Audio CD Player/
Tuner etc.
XLR pin assignment
1. COMMON
2. HOT (+)
3. COLD (−)
AUDIO IN
AUDIO OUTAUDIO OUT
Wall socket
