Espa Evopool SilenPlus ControlSystem - Maintenance; Equipment Care; Declaration of Compliance; Product Compliance

32 pages

To Next Page

To Previous Page

Fig.4 / Abb.4

1: Filtración / Filter / Filtration / Filtern = Filtration Plus

2: Lavado / Backwash / Lavage / Rückspülen = Backwash Plus

3: Enjuague / Rinse / Rincage / Nachpülen = motor 100%

4: Desagüe / Waste / Vidage / Entleeren = motor 100%

5: Circulación / Recirculate / Circulation / Zirkulieren = motor 100%

6: Cerrado / Closed / Fermé / Geschlossen = motor off

Fig.5 / Abb.5

Fig. 6 / Abb. 6

Esquema de conexiones

Connection Diagram

Schéma électrique

Schaltplan

Schema di collegamento
