ESPRIT X6 - Assembly Pack Check List

2
Assembly Pack Check List
STEP
2
.
STEP
3
.
STEP 1.
#44- 5/16” Flat
Washer (8pcs)
#45- 5/16" Curved
Washer (1pc)
#102- 5/16" × 3/4" Socket
Head Cap Bolt (9 pcs)
#53- M5 × 12 mm Phillips
Head Screw (4pcs)
#46- 5/16" ×1.5T
Split Washer (9pcs)
#43- 5/16" × 3/4" Button
Head Socket Bolt (1pc)
#100- 8.5x23x1.5T
Flat Washer (1pc)
#55- 5/16" Nyloc
Nut (2pcs)
#56- 5/16" ×1-3/4" Button
Head Socket Bolt (2pcs)
#43- 5/16" × 3/4" Button
Head Socket Bolt (1pc)
#55- 5/16" Nyloc
Nut (2pcs)
#56- 5/16" ×1-3/4" Button
Head Socket Bolt (2pcs)
#52- 5 × 12mm Sheet
Metal Screw (4pcs)
#100- 8.5x23x1.5T
Flat Washer (1pc)
#43- 5/16" × 3/4" Button
Head Socket Bolt (4pcs)
