CONTENTS
1. Technical Information
2. Important Notes
3. Dimensions
4. Installation
a. Installation of the stove
b. Chimney installation
c. Ventilation
d. Oil supply
5. Positioning of the logs
6. Installing the stove
7. Customer briefing
8. Trouble-shooting chart
9. Spare parts
1. TECHNICAL INFORMATION
FUEL – Set for either Kerosene or Diesel – USE only the correct oil
(Check data plate).
DO NOT USE GASOLINE, CRANKCASE OIL, OR ANY OIL USING
GASOLINE.
Oil consumption MAX 16.5 cc/min
0.99 gal/hr
Oil consumption MIN 6 cc/min
0.36 gal/hr
Heat input MAX 10.4kW (35,500 Btu/h)
Heat input MIN 3.8kW (13,000 Btu/h)
Heat output MAX 6.9kW (23,600 Btu/h)
Heat output MIN 2.76kW (9,500 Btu/h)
Oil connection ¼” NPT
Electrical supply NONE
Weight packed (approx) 100kgs
MAX efficiency 73%
2. IMPORTANT NOTES
The installation must be in accordance with the regulations of authorities
having jurisdiction. The installation must be carried out by a qualified person.
If the chimney has previously been used to burn solid fuel, the chimney
should be swept before the stove is installed.
Oil burning appliances shall be connected to flues having sufficient draft at all
times, to ensure safe and proper operation of the burner.
