10
F
ig.6
Lightly brush surfaces with
a wire brush and vacuum
up debris. Lift hotplate
with care and place on
newspaper or an old sheet.
Fig.7
F
ig.8
Fig.9
FLUE BOX AND REAR FLUE WAY
Remove the front of the flue connector
box and insert the flue brush from left to
right, angling the brush down at 45°.
Once you find the flue way entrance push
the brush down until it stops then gently
but firmly pull back and forth 3 or 4 times
then remove the brush. Dislodged soot
will fall into the tray between the ovens.
RIGHT SIDE FLUE WAY
Next insert the brush at a shallow angle as shown above. The brush will need to turn 90° into the
flueway so steady pressure will be needed to help the brush head round the bend. Once in, work the
brush up and down and front to back as the flue way runs along the entire depth of the ovens. Again,
soot will fall into the trap between the ovens.
