The CSPOLA600 / CSPOLA600C's main components are shown below.
1. LCD screen: for displaying charts (Optotype)
2. IR Cover: for receiving signals from the remote
control
3. LED Lamp
4. Wall mount hole
5. Power switch: for powering the unit ON and OFF
6. Power socket: for connecting the power supply
7. Brightness adjustment
8. USB port for remote control: for communicating
with the remote control and main control box
9. USB port : port for upgrade and recharging remote
control
10. RS232 : Connector for data communication
connectable to the APH500.
11. Vent
CSPOLA600 / CSPOLA600C - Polarized visual chart system > V5 - 03-2018
20
USER MANUAL> V. CONFIGURATIONS
