Description
2 Description
Layout of the combustion chamber (20 - 140 kW)
The replacement combustion chamber consists of the
combustion chamber stones and the associated seals.
Sizes 1-3 are built in the same way. Only the size
of the components varies slightly.
Fig. 2-1: Combustion chamber
Fig. 2-2: Design
