Technical Data18
3.3 Electrical Data
3.3.1 Power Supply
3.3.2 PC Interface
3.3.3 ETK Interface
note
All calibration interfaces (ETK, CAN, K-Line) and the PC interface are DC-decou-
pled.
Item Characteristics Value
Operating voltage rev.-volt. protected 6…32 V
Current consumption Continuous operation 500 mA at 12 V
Wait mode 3 mA at 12 V
Characteristics Value
Connection 10/100 MBit/s; Base-T Ethernet
Protocol TCP/IP
IP address 192.168.40.10
Subnet mask 255.255.255.0
Characteristics Value
Transfer rate (single mode) 8 MBit/s
Transfer rate (block mode) 8 MBit/s, 100 MBit/s
