ETC Sensor - Introduction to Sensor Portable Pack; Electronics Module

Sensor Portable Pack User Manual 3
Reset
Address
Phase A
DMX
Phase B
Phase C
Error
IAS
Analog
AMX
OutIn
Beacon
AMX192
Off On
Switch
Termination
In DMX512
Off On
Thru
Switch
Termination
0 - 10 VDC
Analog
❶
❷
❸
❹
❺
❶ LED beacon
❷ Input connector panel
❸ Electronics module (MPE shown)
❹ Door
➎ Circuit breakers
SP6 Portable Pack
Introduction
The Sensor Portable Pack is a modular dimming system that
consists of a single electronics module and multiple dimmer
modules in a fan-cooled, aluminum and steel housing. It is
available in standard and Advanced Features (AF) configurations.
