-6-
2．General Specification
Function
Simultaneous measurement of two AC voltage, current, phase
between voltage, phase between current, phase between
voltage and current, frequency, phase sequence, active power,
reactive power, apparent power, power factor, distinguish
transformer wiring group, inductive and capacitive circuits, test
second circuit and bus differential protection systems, read the
phase relationship between CTs of the differential protection,
check the meter wiring right, repair lines and equipment, etc.
Power
DC9V alkaline batteries（1.5V AA×6）
Consumption
About 70mA at most with enabled backlight, battery working
continuously for about 14 hours
About 40mA with disabled backlight, battery working
continuously for about 20 hours
Display Mode
LCD display, 240dots×160dots
Meter Size
Length, Width, Height：196mm×92mm×54mm
Clamp Size
acuminate current clamp:7.5mm×13mm (optional)
round current clamp:35mm×40mm (optional)
Measurement
Range
(automatic
shift)
AC Voltage：0.00 V～600V (automatic shift)
AC Current：0.0mA～20.0A (automatic shift)
Phase：0～360°
Frequency：45.00Hz～65.00Hz
Active Power：0.0W～12kW
Reactive Power：0.0W～12kVAR
Apparent Power：0.0W～12kVA
Power Factor：-1～+1
Resolution
Voltage：AC 0.01V
Current：AC 0.1mA
Phase：0.1°
Frequency：0.01Hz
Active Power：0.1W
Reactive Power：0.1VAR
Apparent Power：0.1VA
Power Factor：0.001
Sample Rate
About 2 times/second
Data Hold
Press HOLD key to keep data, "DH" symbol appears
Data Storage
1500 sets
RS232
Interface
USB-RS232 interface, download data to computer for analysis
and management
Automatic
Automatic shutdown about 15 minutes later after launching to
