Etesia HYDRO 124D - TECHNICAL SPECIFICATIONS; ALTERNATOR FUNCTIONALITY

- 7 -
TECHNICAL SPECIFICATIONS
Description Value Unit
Cylinders 3 N
Displacement 916 Cm3
Bore 72 Mm
Stroke 75 Mm
Compression ratio 22.8 : 1
Power (at 3600 rpm) 23.4 CV
Maximum torque (at 2000 rpm) 53.5 N.m
Operating speed 2850 Rpm
Idling speed (minimum) 1200 Rpm
Oil sump capacity With filter :2.4 / without filter : 2.3
Litre
Weight (empty) 85 kg
ALTERNATOR
The alternator is placed at one end of the crankshaft and is integrated with the flywheel.
The latter provides a voltage of approximately 24-27 Volts (Alternative current)
at maximum rate.
