4 • DESCRIPTION OF GRAPHICAL SYMBOLS
CONTROLS IDENTIFICATION
LABEL A : THROTTLE CONTROL LEVER
(PHE - PHTS)
a- START position to start by cold engine.
b- Engine rate setting range
1- Maximum rate
2- Minimum rate
LABEL A : THROTTLE CONTROL LEVER
(PHTB)
a- START position to start by cold engine.
b- Engine rate setting range
1- Maximum rate
2- Engine stop
LABEL B : PHTB SPEED VARIATOR
CONTROL
a - Speed adjustement range
1 - Maxi speed
2 - Mini speed
LABEL C : DRIVE CONTROL
(PBTS - PHTS - PHTB)
- To move forward, push the control lever against
the handlebar.
- To stop, release the control lever.
LABEL D : MOTOR STARTING AND
STOPPING CONTROL
(PHE -PHTS - PBE -PBTS)
1- Starting
1- Press the safety lever against
the handlebars.
2- Pull on the starter handle.
2- Stopping
- Release the safety lever.
LABEL E : PHTB BLADE CLUTCH
CONTROL START
START
1- Swing the blade clutch lever towards top
2- Push the blade clutch lever hock towards front
3- Fold the blade clutch lever on the handlebar
STOP
- To stop the blade release the blade clutch lever:
The blade is on stop and braked
