5• TECHNICAL SPECIFICATIONS
PBE PBTS PHE PHTS PHTB
Engine Briggs & stratton Honda GCV 160 Honda GCV 160
650E Series Quantum XPN55 4 STROKE + Brake OHC 4 STROKE + Brake OHC 4 STROKE
Piston displacement 190 cm3 160 cm3
Stroke 51,99 mm 50 mm
Bore 68,26 mm 64 mm
Maximum power 5 HP / 3,7 kW at 3600 rpm 5,5 HP / 4,1 kW at 3600 rpm
at the shaft output
Use rate 2900
rpm 2950 rpm
Starter
Recoil
Tank capacity 1,5 l 1,1 l
Oil tank capacity 0,6 l 0,55 l
Fuel Unleaded fuel
Cooling
Air cooled
Air Filter
Paper cartridge
Ignition
Electronic
Spark plug Standard Ø 14 mm Standard
Ø14 mm
Thread length : 9,5 mm Thread length : 19 mm
Electrode gap 0,75 mm
Blade coupling Shearing washer Transmission belt
device
Blade stop Engine break Blade break
Cutting width 46 cm
Cutting height 25, 33, 45, 60, 75, 88 mm
To set on each wheel
Wheel diameter Front 180 mm
Rear 200 mm
Weight 31 kg 36 kg 32 kg 37 kg 41 kg
Box capacity 52 l
Forward speed 3,4 kph 3,4 kph 3 to 4 kph
by variator
Noise level at
control position* 86 dB(A) 84 dB (A)
Vibration levels 3,5m/s2 (a
hw
) 2,5 m/s2 (a
hw
)
at the handle **
* Reference standard for mesurements = EN 836
** Reference standard for mesurements = EN 1033, EN 836
