ETNA EFE509WIT - Appliance Description EFK769; Control Panel Overview EFK769

EN 5
APPLIANCE DESCRIPTION
Appliance description
Hotplate (EFK769)
1 – Cooking zone left front
2 – Cooking zone left back
3 – Cooking zone right back
4 – Cooking zone right front
Cooker
A – control panel
B – oven
C – storage space
D – adjustable feet
Control panel
6 – control knob for oven functions
7 – indicator light oven
8 – control knob for oven temperature
9 – indicator cooking zone
10 – control knob for cooking zone 2
11 – control knob for cooking zone 1
12 – control knob cooking zone 4
13 – control knob for cooking zone 3
