EN 15
S U VT
2. Disconnect the electrical connections “W” and “X” and remove item “Y”.
W X YW
X
Y
3. Remove the screws, disconnect the electrical connection “Z” and remove the top hinge.
Hold the door tight.
4. Carefully lift the door from the lower hinge and place it on a padded surface to prevent
scratching.
Z
5. Move the door handle from the left side of the door to the right side.
INSTALLATION AND CONNECTION
