EN 17
9. Slide the door back on to the lower hinge, making sure that the lower hinge pin fits into the
lower hole of the door.
10. Place the supplied top hinge on the opposite side and move the cable over it. Secure the
parts with the screws..
11. Make the electrical connection and fit the cover plate that was supplied.
12. Rotate cover plate “U” 180 ° and replace the cover plates “U” and “S”.
U
S
INSTALLATION AND CONNECTION
